BOSCH Rotary Hammer with SDS Plus 2Kg 600W 3Functions GBH220

Bosch’s GBH 220 Professional rotary hammer with SDS-plus technology is the ideal compact entry-level solution for hammer drilling. Its powerful 720 W motor and 2.0 J of impact energy make for effective hammer drilling in concrete of up to 22 mm in diameter.

Versatility and convincing results are safeguarded by the three-mode rotary hammer for hammer drilling, drilling, and chiseling.

This compact rotary hammer offers professional Bosch hammer performance within reach.

TECHNICAL DATA

Performance data
Impact rate at rated speed – 0 – 4,800 bpm

Additional data
Rated input power – 720 W
Impact energy (according to EPTA 05/2016) – 2 J
Weight – 2.3 kg
Tool holder – SDS plus

Drilling range
Drilling dia. concrete, hammer drill bits – 4 – 22 mm
Max. drilling diameter in metal – 13 mm
Max. drilling diameter in wood – 30 mm

Total vibration values (Hammer drilling in concrete)
Vibration emission value ah – 14.7 m/s²
Uncertainty K – 1.5 m/s²

Total vibration values (Chiselling in concrete)
Vibration emission value ah – 11.9 m/s²
Uncertainty K – 1.5 m/s²

Hammer drilling in concrete
Vibration emission value ah  – 14.7 m/s²
Uncertainty K – 1.5 m/s²

Chiselling in concrete
Vibration emission value ah – 11.9 m/s²
Uncertainty K – 1.5 m/s²

The A-rated noise level of the power tool is typically as follows: Sound pressure level 93.5 dB(A); Sound power level 104.5 dB(A). Uncertainty K= 3 dB.
