Analog Actuator 082H8057 24V AC 0-10V DANFOSS AME 110 NL
Danfoss’ energy-efficient technologies, such as thermostats, high-pressure pumps, digital and electric solutions and motors reduce emissions on a global scale. At the same time, our climate-friendly technologies enable the sustainable transition at the lowest possible cost with relatively short pay-back times.
The actuators are used together with automatically balanced combination valve type AB-QM for DN 10-32.
The actuator can be used with fan coil units, induction units, small reheaters, coolers, and zone applications in which hot/cold water is the controlled medium.
Main data:
• Gap detection at stem up position
• Modulating control
• Force switch-off at stem down position
prevents overload of actuator and valve
• No tools required for mounting
• Maintenance-free lifetime
• Low-noise operation
• Self-positioning process
• Halogen-free cables
